Support for Model: PSS8B2W/G
| General Information | ||
| Spec Sheet | Operators Manual | Parts List |
| Tri-Fold | ||
| Drawings | ||
| Outline Drawing | Outline Drawing DXF | 3D Drawing |
| Engine | ||
| Operators Manual | EPA Certificate | |
| Generator | ||
| Spec Sheet | Operators Manual | |
| Additional Information | ||
| Battery Charger | Battery | Shock Mounts |
| Circuit Breakers | DSE3110 Manual |
Additional Information
| Watts LP | 8400 |
|---|---|
| Amps LP | 35 |
| Watts NG | 7600 |
| Amps NG | 32 |
| Voltage Regulation | Capacitor |
| Voltage Output | 120/240 Volt Single Phase |
| Engine Brand | Briggs |
| Fuel | LP/NG |
| Emissions | CARB/California, EPA Prime, EPA Standby |
| Dimensions | 36" x 29.75" x 27.375" |
| Weight | 388 lbs. |
| Unit Warranty | 1 yr/1000 hrs |
| Assembled In | USA |
Question
Bob Parks –
I am looking for an 8 KW permanent generator to be connected like a portable generator without an ATS. Your site makes no mention of an ATS. Do you mean for it to be connected with a hose for the propane and a cable for the electrical?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Watch Flag for removal
Robby Goodale –
WHAT DO YOU MEAN BY “ATS”?
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
Dale Riebel –
Robby, ATS stands for Automatic Transfer Switch.
Upvote if this was helpful (0) Downvote if this was not helpful (0) Flag for removal
